Cougar/XR7 (67-70) Radiator

EC338-338FS11SP

EC338-338FS11SP

EC338-338FS11SP
Click to enlarge image(s)

Champion Cooling All Aluminum Radiator
Plus Ledfoot Racing Aluminum Shroud and 2-11" SPAL Medium Profile fans
2-Row Core | Cools 400hp

Radiator Dimensions:
Total: 21" (22" with cap) x 25.75" wide (including brackets)
Core: 16.5" tall x 24.25" wide x 1.75" thick
Inlet: 1.5" passenger side
Outlet: 1.75" passenger side
Tanks: 2.5" thick
Tubes: 0.75" thick
Total Thickness: 5.5" to back of fans, 4.5" at center
Fan Thickness: 2.44"

Saddle or Bracket Mounted

13lb. Radiator Cap included
Transmission Cooler Included (1/8-27npt)



CC338-338FS11SP

CC338-338FS11SP

CC338-338FS11SP
Click to enlarge image(s)

Champion All Aluminum Radiator
Plus Ledfoot Racing Aluminum Shroud & 2-11" SPAL Medium Profile fans

Radiator Dimensions:
Total: 21" (22" with cap) x 25.75" wide (with brackets)
Core: 16.5" tall x 24.25" wide x 2.25" thick
Inlet: 1.5" passenger side
Outlet: 1.75" passenger side
Tanks: 2.5" thick
Tubes: 0.63" thick
Total Thickness: 5.5" to back of fans, 4.5" at center
Fan Thickness: 2.44"

Saddle or Bracket Mounted

Transmission Cooler Included (1/8-27 npt)
Radiator Cap Included



MC338-338FS11SP

MC338-338FS11SP

MC338-338FS11SP
Click to enlarge image(s)

Champion All Aluminum Radiator Plus
Ledfoot Racing Aluminum Shroud
 & 2-11" SPAL Medium Profile fans
4-Row Core: Polished Tanks | Cools 700hp

Radiator Dimensions:
Total: 21.75" tall (22" with cap) x 25.38" wide (including brackets)
Core: 16" tall x 24.25" wide x 2.75" thick
Inlet: 1.5” passenger side
Outlet: 1.75" passenger side
Tanks: 3.13" thick
Tubes: 0.63" thick
Total Thickness: 6" to back of fans, 5" at center
Fan Thickness: 2.44"

Saddle Mounted or Bracket Mounted

13 lb. Radiator Cap included
Transmission Cooler Included (1/8-27 npt)
