See Part#CC6677 if you need Top hose in center
EC251-6

EC251-6

EC251-6
Click to enlarge image(s)

Champion All Aluminum Radiator
2-Row Core | Cools up to 300hp

Radiator Dimensions:
Total: 21.75" tall x 19.63 wide (with brackets)
Core: 16.38" tall x 17.25" wide x 1.63" thick
Inlet: 1.25" passenger side
Outlet: 1.25" driver side
Tanks: 2" thick
Tubes: 0.75" thick

Bracket Mounted

13lb. Radiator Cap included
Transmission Cooler Included (1/8-27NPT)
Aluminum Fan Shroud for One 16" Electric fan is also available (sold separately)

Recommended Cooling Fans:
16" Electric Cooling Fan (sold separately)

Note: When buying our 16" Electric Fan make sure there's room for the 3.5" Fan thickness



Compatible With
Ford Falcon 1960-1965 200ci 3.3L I6
Mercury Comet 1961-1965 200ci 3.3L I6
Ford Mustang 1965-1966 200ci 3.3L I6
Ford Ranchero 1960-1965 200ci 3.3L I6
Ford Econoline Van 1961-1965 200ci 3.3L I6
