Cougar/XR7 (67-70)
scroll down for additional options
AE338

AE338

AE338
Click to enlarge image(s)

American Eagle All Aluminum Radiator
2-Row Core 1" Tubes | Cools up to 650hp

Radiator Dimensions:
Total: 21" (22" with cap) x 25.5" wide (including brackets)
Core: 16.5" tall x 24" wide x 2.15" thick
Inlet: 1.5" passenger side
Outlet: 1.75” passenger side
Tanks: 2.5" thick
Tubes: 1" thick

Saddle or Bracket Mount System

16 lb. Radiator Cap included
Transmission Cooler included (1/8-27NPT)
Aluminum Fan Shroud for One 16" Electric Fan or 2-12" Electric Fans is also available (sold separately)

Recommended Electric fans:
One 16" or two 12" Electric fans recommended for this core size (sold separately)



Buy the Fan and Shroud Combo, and Save!
Compatible With
Ford Mustang 1967-1970 (all engines)
Ford Fairlane 1969 (all engines)
Ford Ranchero 1969 (all engines)
Mercury Cougar/XR7 1967-1970 (all engines)
AE338-338FS11SP

AE338-338FS11SP

AE338-338FS11SP
Click to enlarge image(s)

American Eagle All Aluminum Radiator Plus
Ledfoot Racing Shroud
and 2-11" SPAL Medium Profile fans
2-Row Core, 1" tubes | Cools up to 650hp

Radiator Dimensions:
Total: 21" (22" with cap) x 25.5" wide (including brackets)
Core: 16.5" tall x 24" wide x 2.15" thick
Inlet: 1.5" passenger side
Outlet: 1.75” passenger side
Tanks: 2.5" thick
Tubes: 1" thick
Total Thickness: 5.5" to back of fans, 4.5" at center
Fan Thickness: 2.44"

Saddle or Bracket Mount System

Polished Champion 16 lb Radiator Cap included (Pictured Above)
Transmission Cooler Included (1/8-27npt)



Compatible With
Ford Mustang 1967-1970 (all engines)
Ford Fairlane 1969 (all engines)
Ford Ranchero 1969 (all engines)
Mrecury Cougar/XR7 1967-1970 (all engines)
